A knitted PVC spray hose is an enhanced version of a standard PVC spray hose. It features an additional layer of knitted or braided reinforcement, usually made from materials like polyester or nylon, woven tightly around the PVC core. This knitted layer significantly improves the hose's strength, durability, and resistance to abrasion, punctures, and bursting under high pressure. The knitted design also adds structural stability, reducing the risk of kinking and ensuring a steady flow of water or spray. Knitted PVC spray hoses are ideal for heavy-duty applications, such as industrial cleaning, agricultural spraying, or high-pressure washing, where added durability and longevity are critical. The combination of PVC's flexibility and the knitted layer's reinforcement makes this type of hose both reliable and long-lasting.
Korean technology. Double layers Special formula compounding with high tight knitting polyester structure.(W.P.60BAR,B-P-220BAR) Light weight and easy handle than normal rubber steel reinforced hose. High tenacity,elasticity and light weight. Excellent resilience. Excellent abrasion resistant, aging resistant.
High pressure industrial applications
Pesticide & water spray equipment in agriculture
Compressed air in garages and service stations
Factory air line
Automation machinery and pneumatic tools
Construction works
Air plumbing
Good flexible and durability against climate.
TEMPERATURE -5°C-+65°C
PART # | SIZE | ID | OD | WP | BP | LENGTH | WEIGHT | MEASUREMENTS |
INCH | MM | MM | BAR | BAR | M | KG | MMXMMXMM | |
SZSPRHS-6.5 | 1/4 | 6.5 | 12 | 60 | 180 | 100 | 9 | 380X185X135 |
SZSPRHS-8.5 | 5/16 | 8.5 | 14 | 60 | 180 | 100 | 12 | 430X185X140 |
SZSPRHS-10 | 3/8 | 10 | 16 | 50 | 150 | 50 | 8 | 420X185X130 |
SZSPRHS-13 | 1/2 | 13 | 19 | 40 | 120 | 50 | 12 | 470X185X170 |
